12 VOLT SELF PRIMING PRESSURE DIAPHRAGM PUMP 13.2L/M FL35

12 Volt Self Priming Pressure Diaphragm Pump 13.2L/M FL35

Automatic Water Pressure for Caravans, Boats & Off-Grid Systems

Need a reliable water pump for your caravan, boat or off-grid water system? The XC-SP 006/ FL35 12 Volt Water Pump is a compact, self-priming diaphragm pump designed to deliver convenient water pressure wherever you need it.

With a maximum flow rate of 12.5 litres per minute and pressure of up to 2.4 bar (35 PSI), this 12V water pump is ideal for supplying water to taps, showers and other compatible water systems.

One of its most convenient features is the built-in automatic pressure switch. Simply open your tap and the pump starts supplying water. When you close the tap, the pump automatically switches off, making it easy to manage your water supply without manually operating the pump.

The pump also features self-priming capability of up to 1 metre, allowing it to be installed above your water tank under suitable conditions.

Built with a heavy-duty diaphragm, durable motor and integrated protection features, the XC-SP 006/ FL35 offers a practical solution for mobile water systems, agricultural equipment and general water transfer applications.

Why You'll Love It

• Automatic On-Demand Operation: The built-in pressure switch automatically starts and stops the pump when taps or valves are opened and closed.

• Maximum Flow Rate of 12.5 L/min: Provides water flow for compatible taps, showers and water supply systems.

• Up to 2.4 Bar Pressure: Delivers useful water pressure for mobile and off-grid applications.

• 12V DC Operation: Ideal for battery-powered water systems.

• Self-Priming Design: Can draw water from a source up to 1 metre below the pump under suitable conditions.

• Built-In Pressure Switch: Makes everyday operation convenient without needing to manually switch the pump on and off.

• Dry-Run Protection: Automatically switches the pump off when dry-running conditions are detected.

• Included Water Filter: Helps prevent debris from entering the pump.

• Heavy-Duty Diaphragm: Designed for reliable performance in compatible water transfer applications.

• Compact Design: Easy to install in caravans, boats and other areas where space is limited.

• Convenient Port Fittings: Plug-in connections help simplify installation.

• Durable Motor: Features a permanent magnet motor with ball bearings and long-life brushes.

Automatic Water Pressure Made Easy

The XC-SP 006/ FL35 12 Volt Water Pump is designed to make supplying water simple and convenient.

Its built-in pressure switch automatically controls the pump based on water demand.

When you open a tap or valve, the pump starts supplying water. Once you close it and pressure builds in the system, the pump automatically switches off.

This makes it particularly useful for caravans, boats, camper vans and other installations where you need water pressure without manually operating a pump.

The included filter also helps protect the pump from debris, while its self-priming design gives you more flexibility when positioning the pump near your water tank.

Ideal Applications

• Caravans & Motorhomes: Supply water to taps, basins and compatible shower systems.

• Boats: Provide automatic water pressure for onboard freshwater systems.

• Camper Vans & Camping Setups: Create a convenient portable water supply.

• Reverse Osmosis Systems: Suitable for compatible water purification installations, subject to the system's pressure requirements.

• Agricultural Spraying: Supply water to compatible farming and mobile spraying equipment.

• Industrial Equipment: Useful for low-voltage water transfer and pressure applications.

• Printing Equipment: Suitable for compatible liquid transfer systems.

• Off-Grid Water Systems: Operate from a suitable 12V DC power supply.

Product Specifications

Specification	Details
Model	XC-SP 006 / FL35
Pump Type	Automatic Diaphragm Pump
Operating Voltage	12V DC
Maximum Flow Rate	12.5 L/min (3.3 GPM)
Maximum Pressure	2.4 Bar (35 PSI)
Stated Maximum Static Lift	24 m
Current	7A
Self-Priming Height	Up to 1 m
Automatic Pressure Switch	Yes
Dry-Run Protection	Yes
Water Filter	Included
Maximum Water Temperature	50°C
Diaphragm / Seal Options	EPDM or Viton, depending on model configuration
Motor Type	Permanent Magnet Motor
Operating Cycle	30 Minutes ON / 10 Minutes OFF
Pump Design	Non-Continuous Duty

Built for Convenient Installation

The XC-SP 006/ FL35 features a compact design and convenient plug-in port fittings, making it easier to install in a range of water supply systems.

Its self-priming capability of up to 1 metre allows the pump to draw water from a tank positioned below the pump, while the included filter helps reduce the risk of debris entering the system.

The pump is designed so that no metal components come into contact with the liquid being pumped.

For applications involving chemicals or specialised liquids, always confirm that the fitted diaphragm and seals are compatible with the intended liquid.

Important Operating Information

This pump is designed for intermittent use and must not run continuously.

To help protect the motor and extend the lifespan of the pump:

• Maximum Running Time: 30 minutes per operating cycle.

• Cooling Period: Allow at least 10 minutes between operating cycles, or longer if needed for the motor to cool.

• Maximum Water Temperature: Do not exceed 50°C.

• Secure Connections: Ensure all hoses and fittings are properly sealed to prevent leaks and unnecessary pressure switch cycling.

• Correct Power Supply: Use a suitable 12V DC supply capable of delivering the required current.

• Filter Maintenance: Regularly inspect and clean the included filter to maintain water flow.

• Dry-Run Protection: Although the pump includes automatic dry-run protection, avoid intentionally operating it without water.

For best results, install the pump according to the manufacturer's recommendations and ensure it is suitable for your intended water system.
