24 VOLT 14 BAR PRESSURE DIAPHRAGM PUMP 10L/M

24 volt DC 14 bar Pressure Diaphragm Pump 10L/m

Powerful High-Pressure Water Pump for Cleaning, Spraying & Misting

Need serious water pressure from a compact 24V pump? The 24 Volt DC 14 Bar Pressure Diaphragm Pump is designed for applications that require strong water pressure and reliable water flow, making it ideal for portable cleaning equipment, agricultural spraying and high-pressure misting systems.

With a maximum pressure of 14 bar (200 PSI) and a maximum flow rate of 10 litres per minute (600 L/h), this pump delivers powerful performance for a range of domestic, agricultural and commercial applications.

Featuring a five-chamber diaphragm design, the XDP200B is built to deliver higher water volumes while maintaining strong pressure. Its self-priming capability of up to 1.5 metres also makes it convenient for drawing water from suitable tanks and containers.

The built-in automatic pressure switch helps control the pump according to system pressure, while the included fittings and pre-filter make installation easier.

Whether you're washing vehicles, operating agricultural spraying equipment or setting up a patio misting system, this compact 24V diaphragm pump offers a practical solution for applications requiring high pressure and controlled water delivery.

Why You'll Love It

• Powerful 14 Bar Pressure: Delivers up to 200 PSI for demanding cleaning and spraying applications.

• Maximum Flow Rate of 10 L/min: Moves up to 600 litres of water per hour under ideal conditions.

• 24V DC Operation: Ideal for compatible low-voltage and portable pumping systems.

• Five-Chamber Diaphragm Design: Designed for higher-volume water delivery and strong pressure.

• Automatic Pressure Switch: Starts and stops the pump in response to system pressure.

• Self-Priming Up to 1.5 Metres: Can draw water from a suitable source below the pump.

• Dry-Run Capability: Designed to tolerate running dry without immediate motor damage.

• Viton Seals: Suitable for certain compatible liquids within the specified pH range.

• Stainless Steel Shaft: Provides durability for demanding pumping applications.

• Pre-Filter Included: Helps prevent debris from entering the pump.

• Rubber Mounting Feet: Help reduce vibration and operating noise.

• Compact & Portable: Convenient for mobile cleaning and spraying equipment.

• Multiple Connection Fittings: Includes fittings for compatible hose and threaded connections.

Ideal for High-Pressure Applications

The XDP200B 24V High-Pressure Diaphragm Pump is a versatile choice for applications that need strong water pressure and consistent water delivery.

It's particularly useful for:

• Portable Car Washing: Supply pressurised water to compatible mobile car wash equipment.

• Carpet Cleaning Machines: Provide water pressure for suitable carpet and upholstery cleaning systems.

• Agricultural Spraying: Support compatible crop spraying and garden spraying equipment.

• Patio Misting Systems: Supply water to suitable high-pressure misting nozzles.

• Mobile Cleaning Equipment: Ideal for portable cleaning and washing applications.

• Sweepers & Cleaning Machines: Supply water to compatible industrial and commercial cleaning equipment.

• General Water Transfer: Move water in applications requiring higher discharge pressure.

Automatic Pressure Control

The pump features a built-in automatic pressure switch that helps manage water delivery.

When system pressure drops, the pump starts automatically to supply water. Once the system reaches the pressure switch's shut-off setting, the pump stops.

This makes it convenient for cleaning and spraying systems where water is used intermittently.

Important: All hoses, fittings and valves must be properly sealed. Leaks can cause repeated start-and-stop cycling, which may damage the pressure switch and motor.

Product Specifications

Specification	Details
Model	XDP200B
Pump Type	High-Pressure Diaphragm Pump
Operating Voltage	24V DC
Maximum Flow Rate	10 L/min (600 L/h)
Maximum Pressure	14 Bar (200 PSI)
Rated Current	10A
Recommended Fuse	10A
Maximum Self-Priming Height	1.5 m
Pressure Control	Automatic Pressure Switch
Diaphragm Design	Five-Chamber
Seal Material	Viton
Stated Liquid pH Range	4–11, Subject to Chemical Compatibility
Shaft Material	Stainless Steel
Motor Duty	Intermittent Use Only
Operating Cycle	Maximum 30 Minutes ON / 20 Minutes OFF
Weight	5 kg
Dimensions	25 × 13 × 13 cm

What's Included?

The pump is supplied with the following connection accessories:

• 1 × 3/4" Male Thread Connector

• 1 × 1/2" Hose Barb Connector

• 1 × 1/2" Hose Barb Pre-Filter

The included pre-filter helps prevent small particles and debris from entering the pump, supporting reliable operation and making maintenance easier.

For best performance, inspect and clean the pre-filter regularly.

Built for High-Pressure Performance

The XDP200B features a five-chamber diaphragm design that provides strong pressure and higher water flow for demanding applications.

Its stainless steel shaft and Viton seals offer durability, while the rubber mounting feet help reduce vibration during operation.

The pump's compact construction also makes it suitable for portable equipment and installations where space is limited.

For best performance, install the pump vertically as specified and use suitable flexible high-pressure hose.

Because the pump can generate up to 14 bar, all hoses, clamps, fittings and connected equipment must be rated for the required operating pressure.

Important Operating Information

This pump is designed for intermittent operation only and must not run continuously.

To help protect the motor and automatic pressure switch:

• Maximum Running Time: Operate for no longer than 30 minutes at a time.

• Cooling Period: Allow at least 20 minutes OFF between operating cycles and ensure the motor has cooled to ambient temperature before restarting.

• Avoid Frequent Cycling: Repeated starting and stopping can damage the automatic pressure switch.

• Check for Leaks: Poor hose connections, leaking fittings and valves that do not close properly can cause unnecessary pump cycling.

• Maintain Correct Voltage: Use a suitable regulated 24V DC power supply capable of delivering the required current.

• Prevent Low Voltage: Insufficient voltage may prevent the pump from reaching its shut-off pressure, leading to overheating and motor damage.

• Secure All Hoses: Use suitable pressure-rated hose clamps to prevent connections from loosening.

• Use High-Pressure Hose: Ensure all hoses and fittings are rated for the pump's maximum pressure.

• Avoid Kinked Pipes: Keep hoses free from bends and restrictions that could affect water flow.

• Dry-Run Capability: Although the pump can tolerate dry running, avoid unnecessary extended operation without liquid.

• Chemical Compatibility: Confirm that any liquid being pumped is compatible with the Viton seals and all other internal components.

• No Flammable Liquids: Never use this pump to transfer petrol, diesel, solvents or other flammable liquids.

• Correct Installation: Mount the pump vertically and follow the manufacturer's installation instructions.

With its 14 bar maximum pressure, 10 L/min flow rate and five-chamber diaphragm design, the XDP200B is a practical choice for portable cleaning, agricultural spraying and other intermittent high-pressure applications.
